Graco Ultra 495 XT Electric Airless Sprayer Hi-Boy 19D533

SKU: 19D-533
$6,279.00 $5,183.00 (17% off)

Exclusive of GST. Shipping calculated at checkout.

In Stock

Details

A rugged approx. 29.9 kg Hi-Boy cart with a 1.7 HP motor, pressure range of 3.5–227 bar, TurboClean fast flush, and selectable modes—built for high productivity.

Highlights:

  • Fast, stable pressure and flow (up to 2.65 L/min)

  • Pump lasts up to 3× longer; cleans 6× faster

  • Includes gun, hose & RAC X LP 517 tip



  • Powerful Motor – 1.7 HP Xtreme Torque brushless motor for high-flow, efficient spray performance

  • Widest Pressure Range – Fast-response control from 3.5–227 bar for precise finishes across coatings

  • Dual Performance Modes – Low-Pressure and High-Pressure settings for versatility and efficiency

  • Durable Pump – Endurance Vortex piston pump lasts up to 3× longer, with speedy ProConnect replacement

  • Rapid Cleanup – TurboClean flushes system up to 6× faster using half the water

  • Pump Safety – WatchDog system protects the pump from low-fluid damage

  • Easy Maintenance – Easy-Out filter reduces clogging and simplifies upkeep

  • Clear Controls – LED digital display remains visible in any jobsite condition

  • Effortless Mobility – Wheeled Hi-Boy cart design for easy transport

  • Full Kit Included – Comes with Contractor PC Gun, Hose, and RAC X LP 517 SwitchTip



Graco Brochure Ultra XT Range

Features

Xtreme Torque Motor Technology

  • 15x more torque than traditional motors for demanding jobs

  • 8x more magnets deliver powerful, consistent performance

  • 90% lower running speeds extend motor life

  • Runs up to 10x quieter – ideal for indoor or residential sites

Rapid-Response Control

  • Instant pressure adjustments for a consistently smooth finish

  • Maintains top performance across a wide tip size range

  • Massive pressure range: 50–3,300 psi – suits everything from primers to heavy coatings

Selectable Spray Modes

  • Low Pressure Mode (50–2,000 psi) for precision and reduced overspray

  • High Pressure Mode (500–3,300 psi) for maximum performance when you need it

LED Digital Display

  • Easy-to-read screen – even in bright daylight or dusty conditions

Endurance Vortex Piston Pump with ProConnect

  • Vortex Rod lasts up to 3x longer than standard pumps

  • Quick pump changes on site with ProConnect – no tools needed

TurboClean System

  • Clean your pump 6x faster using half the water

  • Designed for fast cleanup between jobs

WatchDog Pump Protection

  • Automatically shuts off the pump when paint runs low – helps prevent dry running

Durable Filtration

  • Easy Out Filter reduces tip clogs and makes cleaning simple

Complete Kit Included

  • Comes ready to go with Contractor PC Spray Gun, RAC X LP 517 SwitchTip, and hose

Specifications

  • Model: Ultra
  • Series: XT
  • Type: Airless Sprayer



Max Tip Size 0.027″
Max Flow Rate 3.0 LPM
Max Pressute 3300PSI
