The Graco Ultra 495 XT stand is a compact 14.1 kg pro-grade sprayer with a 1.7 HP motor, 3.5–227 bar pressure control, TurboClean fast flush and selectable spray modes.
Powerful Motor – 1.7 HP Xtreme Torque brushless motor for high-flow, low-noise performance
Wide Pressure Control – 3.5–227 bar (50–3 300 psi) via Rapid-Response Pressure Control
Dual Modes – Low-Pressure (3.5–138 bar) and High-Pressure (35–227 bar) for optimal control
Long-Life Pump – Endurance Vortex piston pump lasts up to 3× longer, with fast ProConnect replacement
Quick Cleanup – TurboClean system flushes the pump up to 6× faster with half the water
Pump Protection – WatchDog system prevents damage when fluid level is low
Durable Display – LED digital display engineered for all jobsite conditions
Light & Portable – Compact stand unit at 14.1 kg for easy transportation
Complete Kit – Contractor PC Gun, Airless Hose, and RAC X LP 517 SwitchTip included
Xtreme Torque Motor Technology
Delivers up to 15× more torque with an advanced 8-magnet design
Operates at 90% lower speeds for extended motor life and runs up to 10× quieter
Rapid-Response Control
Instant pressure response for consistent spray patterns across all tip sizes
Wide operating range from 50–3,300 psi for maximum application versatility
Selectable Performance Modes
Low Pressure Mode (50–2,000 psi) helps reduce overspray and saves material
High Pressure Mode (500–3,300 psi) delivers peak performance on tough jobs
LED Digital Display
Bright and easy to read — even in direct sunlight or challenging site conditions
Endurance Vortex Piston Pump with ProConnect™
Vortex rod lasts 3× longer than competitive pumps
Fast, tool-free pump swaps with the ProConnect system for minimal downtime
TurboClean™ Cleaning System
Cleans the pump 6× faster using half the water — saves time and resources
WatchDog™ Pump Protection
Automatically shuts off the pump when material runs out, preventing damage
Easy-Out™ Filtration System
Reduces tip clogs and allows quick, tool-free filter changes
Lightweight and Portable
Just 14 kg (31 lb) — easy to move and lift on any jobsite
Complete Ready-to-Spray Kit
Includes Contractor PC™ Spray Gun, RAC X LP 517 SwitchTip, and 15 m hose
Supported nationwide with service and parts availability through authorised centres
Max Tip Size | 0.027″ |
Max Flow Rate | 3.0 LPM |
Max Pressute | 3300PSI |
